Extend Profile Controls content for Railing macros from PowerPack for Autodesk Advance Steel


One of the benefits of the Railing macros, available in PowerPack for Advance Steel, is that the library of profiles used to create the railing can be extended.

In other words, the user can add any section to the Railing macros from the Stairs and Railing Vault.

This feature is available starting with version 2021.1 of PowerPack for Autodesk Advance Steel.

Stairs and Railings Vault

All the Graitec railing macros can be configured to use records from the Autodesk Advance Steel AstorRules database – JointsGUIAllowedSections table. This behavior is like some Advance Steel standard joints.

This flexibility of the macros offers the users to go beyond existing restrictions and extend the list of available sections in the profile selection controls, for each type of main railing element such as:

  • post
  • top rail
  • middle rail
  • kick rail
Profile selection control inside the dialog

To make this work, the following strings (names) for the JointName and JointControl columns in the table, for each railing macro and each main element type inside the macros, must be used:

How it works?

  1. Open the Table Editor from MANAGEMENT TOOLS – AstorRules database – JointsGUIAllowedSections table.
  2. Create a new table entry for the desired user section.

Add a new entry inside JointsGUIAllowedSections table:

Example: add half round solid sections to be used for the top handrail inside the Standard railing macro

New entry in JointsGUIAllowedSections table

Update the database and reload it in Advance Steel using the Reopen database option. Next time the Standard Railing macro is opened, the new type of profile section can be used inside the railing:

Advertisement

Join BIM WORKFLOW WEEK!


BIM WORKFLOW WEEK is an online event organized by GRAITEC for structural engineers and detailers. Nowadays, you can streamline your BIM workflows using Graitec and Autodesk technologies together. Bridge the gap between all stakeholders and discover how you can develop and improve your construction projects in a digital thread!

Each day we will run a webinar to show how easy it is to streamline your daily work! We show how to apply a complete BIM workflow from design to detailing on all your projects during the webinars! Don’t wait and register today!

BIM WORKFLOW WEEK AGENDA:

Monday – 15/03/2021 – CREATE YOUR BIM MODELS WITH REVIT AND SIMULATE THEM WITH ADVANCE DESIGN

Are you a structural engineering company doing construction projects with Revit® from Autodesk in a BIM environment? In this webinar, we will propose you a way to streamline your projects, starting to CREATE BIM data in Revit, exporting it to Advance Design to SIMULATE your building and synchronize back in Revit all changes. Discover how easy it is to link Autodesk Revit and Graitec Advance design to simulate and optimize your steel an concrete projects.

Tuesday – 16/03/2021 – ENRICH YOUR 3D BIM REVIT MODEL WITH ANALYTICAL DATA AND RESULTS USING ADVANCE DESIGN

In this webinar, we will go deeper in the integration between Autodesk Revit and Advance Design: exchanging and synchronizing geometrical data is a good point but is not enough to enable a real BIM structural workflow. During this session, you will discover how to enrich your Revit model with finite element results and theoretical reinforcement values using Advance Design with an effective synchronisation mechanism controlled by the user!

Wednesday – 17/03/2021 – APPLY AN EFFECTIVE BIM WORKFLOW FOR ALL YOUR REBAR PROJECTS IN REVIT!

In this BIM era, it’s time for you to manage your rebar projects with 3D models using Autodesk Revit®! Join us to this webinar and discover how you can use the Autodesk platform and Advance Design together to produce 3D Design-driven rebar cages for Beams-Columns-Footings-Slabs-Walls & Shear Walls, automate the drawing views creation with all tags and annotations, produce final drawings and manage in real time all your rebar projects!

Thursday – 18/03/2021 – STEEL CONNECTIONS DESIGN REINVENTED FOR ADVANCE STEEL USERS!

If you’re a structural engineer or a steel detailer using Advance Steel and want to save time, cost and reduce your carbon footprint, Graitec now offers a solution to complement and optimise your current workflow. To facilitate analysing these complex 3D steel connections, Advance Steel joints can now be exported to Graitec Advance Design Connection!

Friday – 19/03/2021 – APPLY A COMPLETE BIM WORKFLOWS FROM DESIGN TO DETAILING ON ALL YOUR STEEL PROJECTS!

In this webinar, we will go through a complete BIM workflow from design to detailing using Autodesk Advance Steel and Graitec Advance Design together. You will discover how easy it is to design and optimise a steel structure with Graitec Advance Design, including steel joints. Then, we will end by exporting the model to Advance steel to create drawings, BOM lists and CNC files fir the fabrication.

Advance Steel SDNF export – how and where to create new entries?


Recently this question came up from a colleague on how and where you find the Database entries behind the SDNF Export from Advance Steel.   So, this is what is behind todays idea for the blog.

Within Advance Steel there are many different types of Export/import options, the core one of these is the SMLX options for transfer from Advance steel to Revit to Advance Steel, but sometimes over more traditional export formats are needed, in this case the SDNF format (Steel detailing neutral format) was being used to link to a Steel and piping software, the user was using Advance steel to complete their steel process but wishes to update within their piping platform. The simple answer is that the SDNF export uses the Databases called the GTC mapping, but which one, as there are two locations and then which tables, as there are several within the database. So, with this goal in mind, we looked into the actual database and more importantly which table and how the entries in the table are completed.   The conclusions of this and approach is explained in the attached document link, but the summary is that for the export process the GTC mapping database, that is located under the Advance folder of Autodesk within your program files, is where you need to look and it is using the table called the ‘Profile Export conversions’, under the Advance Steel type. Also, the entries for the table can be created using the ‘Autodesk one to one mapping’ or can use the ‘expression format’ that is common within the database entries.

Advance Steel SDNF Export Mapping

Using Advance Steel 2021 version and the for the Export to SDNF option via the ribbon, we look at how to make a section group into the Export systems.

Which Database

For the SDNF mapping the database is the GTC mapping.MDB database, this is found under the Advance\data folder of Autodesk within your program files.

C:\ProgramData\Autodesk\Advance\Data

Note: to see this you may have to enable hidden files and folders under the windows explorer options.

The data base is an Microsoft access database, the best way to edit this is with ‘Access’.

Which Table/s

So the heading says which tables, for good reason, the system actually uses the Profile Export conversion table:

Although if you are creating entries via the mapping dialog that appears in the software, if it finds a beam type not mapped previously, in that case it creates two entries, with the other being in the GTC profile conversion.  If you do create entries manually, you can go in and remove these, as they are not used.

How to find an entry in the table.

For the Access field , you can filter this down by checking the box under the column filter to show only those elements:

In this case just uncheck select all, then scroll the list and check for example HEB

You will see several listings for HEB, some with different GTC standard and export applications listed.

But actuall none of these may be any good to export exactly what you need.  For example the line 1011 would look good for this export to SDNF,  but trying this it is not doing what you would expect.

The issue is coming from the  GTC standard, this does not have the correct reference that is aligned to the entry in the profile master table. That is the tynename text used in the profile master table, under the astorprofiles database.

The HEB reference is using the other table, and obsolete one.

The solution

The easiest way round this is to create a new table reference, to reflect the correct string and references,  so you can either manually do this, or maybe just take a few sections and map them, and look for the entries in the DB table,  they should start with prefix of 20000.

By mapping these manually, the GTC standard is created , so you can use this to form the string required.

If you have Excel this is an ideal platform in which to do this and create them and copy and paste back into Excel.

So, this is the simple way to create a line entry, then copy it out, then use the functions of Excel and expand the entries to cover all the sections from the profile table.  This can take some time to create, but more importantly they add lots of entries to the main DB.

But there is another way to reduce this input.

Single line entry using Expressions

Within the GTC database, the user will notice there are entries, which appear to use a code abbreviation, a formula so to speak.

 These expressions come from a format called regular expressions and there is some good information on this via this website link:  ‘learn RegEx Experssion  this website very useful, very good step by step tutorial.  Take note there are many websites that explain this concept so feel free to google it and suggest others.’

This example the HEB beam mapping.

So from the previous entry in the profile export conversion table we can see the expression elements used in the line, so whilst in Access you can copy the line and paste it into Excel changing the key value to a more suitable entry, then comparing this to the manual lines, we can create a combined entry and paste it back into the Access table.

So with this line pasted back into the Access database, then close any open session of AS, close the access Database, Open the Profile export conversation table, then paste in the new entry, copied from excel.

Using this/ testing.

Create a simple model of the sections in question, then with new session of Advance steel open,  run the process for using these new entries. Select the SDNF button and process the HEB thorough the new table entries. If this is understood correctly and we run the export and the Advance steel mapping is present the process should complete within out the need for one-by-one map process.

The output

Checking the SDNF file format and naming etc, your notepad of notepad ++, you can view the file and see the names created in the listing.

All this from one line in a table, this is the process used, beyond the manual mapping of sections, it is also used for the Revit transfer of objects via the SMLX format, again using these expressions to map multiple entries.  Please see the Autodesk University class that I had the privilege to present, over the Revit AS workflow, you see the same in this class for Revit and AS.

https://www.autodesk.com/autodesk-university/class/Steel-Fabrication-Transfer-Revit-Advance-Steel-Under-Hood-2019

How to find out the start point and direction a beam was created in advance Steel 2018


While searching the forum, I found an intriguing question and I thought I would create a short video to address the issue.

Here is the dilemma, you are working on many projects simultaneously. While jumping from one project to another, you notice that in some of the drawings, your beam orientation is not as you expected.

It would be great if, in the steel structure, you were able to find out the start point of the beam. Did you create the beam from left from right or right from left?

TIP: Advance Steel allows you to view what direction the beam was created.

Open the Advance Steel Tool Palette and select the UCS category, which is the fourth icon in the first column.  Within that category select the second icon called “Define coordinate system” in the third row.

After selecting the beam in question, you will find a symbol as seen in Figure1. The symbol shows you that this beam was created from right to left and in Figure 2 the beam was created from left to right.

How to find out the start point and direction a beam was created in advance Steel 2018

Figure 1

How to find out the start point and direction a beam was created in advance Steel 2018

Figure 2

How to create a BOM of selected elements using the model browser Queries option in Advance Steel 2018


You want to create a BOM based on certain elements in a structure or certain selected elements. This video will show how to accomplish this.

You can create a querie in Advance Steel of certain criteria in your structure based on your selected preference in the Search filter. The Search filter is located on the Advance Steel Management Tools Palette, selection category.

You can create queries based on the object type, Common properties, Number and object Partmarks along with naming, model role, Lot/Phase etc. You can then export the customized BOM in various formats and save it to the automatically created BOM folder of the structure.

Watch the video for more info

How to change the slope dimensions to display in inches or only degree


Here is the issue, you have created a drawing which have sloped dimensions on it. You want the dimensions to display in inches rather than feet. Perhaps you have a client that wants to have the slope dimensions displayed in degrees rather than inches. How do you accomplish this in Advance steel?

This can be done locally on each drawing sheet, however, what if you have the same scenario on hundreds of sheets?

Not to worry. You can make the changes globally and have the changes reflect the created sheets after updating the database and using the force Update for the drawing or by updating the drawing in question.

How to change the piece marks that have an incorrect Phase number


Here is the dilemma, you have created a structure in phases and notice that some elements of the structure don’t reflect the phase. In fact, the piece marks are displaying the wrong phase number in the Model browser and the drawings they were created on.

What do you do, certainly not renumber the entire structure?

Advance steel allows you to remove the numbering and information from the problematic elements using the Toggle switch display SP/MP tool located on the Output tab, Part marks panel.

Watch the video for more info

Video | How to change multiple elements through the model browser


This video shows how to add a model role to multiple elements using the model browser.

The model browser is a powerful tool that allows you to browse, filter, check, and edit your model. You can select certain elements in the browser and isolate them, only these elements will be visible in the structure.

Through the model browser, you can see if a part has been numbered or if it has been assigned a model role.

Add columns for specific criteria regarding Main and single part mark, Main and single part prefix, material, coating.  It is possible to add coating or change Section sizes by putting a check in the Edit properties located in the upper left corner of the window.

Video | How to create claddings in Advance Steel


It is easy to create claddings to a specified area of a structure using the Advance Steel cladding tools, located on the Extended Modeling tab, Structural elements panel. Similar standard panels can also be used for decking.

Simply place the UCS accordingly then define the cladding area using the “Define cladding area tool” once the area is defined create any cut outs or openings using the “Define cladding opening tool”.

Once these parameters are defined you can now create the claddings using the “Create cladding tool”.

Within the properties dialog box, you will find an extensive library of cladding and decking sections where you can adjust the orientation and finishing properties as well as the placement offset, cut per slope and much more!

The 4th Annual Advance Steel Academy 2017 in US is a Success!


Thank you to everyone who made our Annual Advance Steel Academy a success! We are already planning ahead for next year’s event in Baltimore!

The 4th Annual Advance Steel Academy 2017 in US is a Success!

GRAITEC, Autodesk® Platinum Partner, hosted its fourth edition of Advance Steel Academy, an advanced training focused on Autodesk® Advance Steel. This event took place in San Antonio on March 20-22, just before the NASCC, and we welcomed 50 Advance Steel users (this number has doubled from last year!). “The objective of the Advance Steel Academy is for all attendees to develop their Advance Steel skills, learn about trends within the building and construction industry and network with other industry professionals.” Hugo Michaud, Sales Director Americas, Graitec Group.

The first day was met with a buzz of excitement at the historical Menger Hotel as we anxiously awaited our guests’ arrival.

This was my first Advance Steel Academy to attend, and I will continue attending in the future. I learned new tips, tricks and technics on most all seminars. Networking and socializing with fellow Advance Steel users and the tech team proved to be quite beneficial as well. I recommend it to all Advance Steel users!” Lewis Moreland, Owner, EZDrawLLC

The GRAITEC team welcomed Autodesk Advance Steel users with different backgrounds. Steel and Precast Detailers, Steel Erectors, Steel & Precast Fabricators, Structural Engineers, Contractors, etc. gathered for in-depth workshops, technical sessions and networking.

For the third consecutive year, we were joined by Autodesk partners. Michael Gustafson, Industry Strategy Manager for Structural Engineering at Autodesk, talked about Autodesk’s vision for the Future of Structure & BIM. He adds: “Graitec’s Advance Steel Academy event was a big success. I’ve attended this event for three years now, and it has steadily attracted more customers each year. It was a great week having the opportunity to meet with Advance Steel customers at Graitec’s event as well as at NASCC.

The 4th Annual Advance Steel Academy 2017 in US is a Success!

Udo Haedicke, Advance Steel Product Manager, gave an exclusive preview of the new 2018 features. He comments: “What a nice event. Thank you for getting the chance to promote the new features of Advance Steel and the opportunity to chat with so many great customers!

This was my second Advance Steel Academy and it was great. The perfect opportunity to discuss problems, learn new tricks, exchange ideas and share solutions with the Advance Steel experts as well as other users.” Matt Steiger, Detailer/CAD Manager, Mountainview Steel Detailing

Continue reading…

Video | How to Reference Connections Created by Camera to a Key Plan View


Using Advance Steel Cameras at node tool, it is easy to create drawings of connections in your structure and reference them to a plan view.





First define the camera symbol presentation. How do you want the camera symbol to be displayed on drawings?

This can be done from the (ASMT) Advance Steel Management Tools by selecting the Defaults category. Use the filter option and type “Camera in the field.”

Select the detailing camera representation type from Drawing-Presentation sub category > General.

Place the UCS at the level where your connections are located, “Create cameras(s) at node” tool and define the camera direction.

By using the Drawing Process, “Cameras”, you have the option of “Selected cameras” or “All Cameras”.

Choose your required sheet size and the details are automatically created.

From the Drawing style GA Plans, Elevations/Sections category you can choose a ready-made template.

Select the elements you want included on the plan view and the drawing is created with the camera referenced to the plan view.

Advance Steel Academy 2017



Our annual Advance Steel Academy (formerly Advance Steel User Group) is coming up March 20-22, 2017 in San Antonio, TX. For new Advance Steel users who may not have attended in the past, and those who want to know what’s new for this year’s event, have a look at the agenda!

  • Learn features within Advance Steel software that will add great value to your steel detailing process
  • Learn from experts and learn more about the industry than just your day-to-day operations
  • Network with others in the industry, including notable Autodesk leaders
  • A full-day focus on customizing your output (drawing styles)
  • The event takes place the same week and location as the NASCC. Get a free pass!

Learn more and register

GRAITEC upcoming construction & BIM webinars


Autodesk Advance Steel & Plant 3D workflows, Revit Lt Vs. 2D, BIM for Infrastructure and Revit 360 collaboration – Register today!



Advance Steel and Plant 3D Workflow Webinar

This webinar will focus upon the interaction between Autodesk Advance Steel and Autodesk Plant 3D. Learn how existing plant structures can be used as a reference and then transferred to Advance Steel for additional steelwork to be added.

Explore the options to link your Advance Steel model with your plant project.

Webinar Host: John Bennett

Date: 21st September 2016

Time: 4:00 PM – 5:00 PM BST

Click here to find out more and to register!



Revit LT vs. 2D Webinar

This webinar will introduce users to working in a more intelligent way. Replacing lines, and circles with ‘real-world’ components that interact with its surrounding environment.

We will also look at the benefits of modelling the whole building rather than working on isolated areas, which can introduce potential errors.

Webinar Host: Simon Dickinson

Date: 22nd September 2016

Time: 10:00 AM – 11:00 AM

Click here to find out more and to register!



BIM for Infrastructure Webinar

This session will look at the workflows between early concept through to finished design; as well as focusing on the advantages of using Infraworks and Civil3D.

Ian Robinson will highlight the ease of looking at different design options using real-world data such as georeferenced data. This will allow the user to consider potential issues such as flooding.

Webinar Host: Ian Robinson

Date: 23rd September 2016

Time: 10:00 AM – 11:00 AM

Click here to find out more and to register!



Revit 360 Collaboration Webinar

This webinar will look at the new cloud subscription service that enables users to centralise their models via. The cloud.

The tool will keep all parties connected in real time using the communicator tool.

Webinar Host: Simon Dickinson

Date: 28th October 2016

Time: 10:00 AM – 11:00 AM

Click here to find out more and to register!

GRAITEC Delivers Autodesk Advance Steel Detailing Software Training During its Annual User Group


Each year GRAITEC hosts a North America advanced training focused on Advance Steel, Autodesk’s structural steel detailing software. This year the User Group took place in Orlando, Florida on April 26-28.

GRAITEC User Group welcomed Autodesk Advance Steel users from US and Canada and from all areas of the building and construction industry, including Steel and Precast Detailers, Steel Erectors, Steel & Precast Fabricators, Structural Engineers and Contractors. This 3 day event included in-depth workshops, technical sessions and networking.

The objective of the User Group is for all attendees to develop their Advance Steel skills, learn about trends within the building and construction industry and network with other industry professionals.Hugo Michaud, Graitec General Manager Americas.

For this second edition, GRAITEC was pleased to welcome once again Michael Gustafson, P.E. Autodesk Industry Strategy Manager, Structural Engineering who talked about the Future of Advance Steel, and presented all the new features available in the 2017 version.

The User Group attendees explored the extensive portfolio of GRAITEC and Autodesk latest advanced BIM technology. Indeed, GRAITEC experts gave intense training on various topics: Management Tools Database, Connectors & Special Parts, Custom Connection, Project Management & Mutli User, Plateworks, Drawing Styles Customization etc.

I liked seeing the capabilities of Advance Workshop, GRAITEC’s Steel Fabrication Management Information SoftwareBill Wellman, NCI Buildings Systems

This event allowed GRAITEC to introduce Advance Workshop, its steel fabrication management information software. One-on-One sessions took place in order to discuss about its BIM workflow with Advance Steel, its ERP Systems integration, its real-time material traceability and more. GRAITEC demonstrated how Advance Workshop enables companies to drive increased efficiency and improved profitability.

The Drawing Styles session revealed many hidden features!Tim Schroder, Enginuity Engineering & Design

Professionals of the industry learned about the latest BIM solutions which will help them win and complete more projects with even greater accuracy and efficiency such as:

  • Autodesk Structural Fabrication Suite, the new Autodesk complete toolset for structural engineers and fabricators which combines Navisworks Simulate, AutoCAD, Revit and Advance Steel).
  • The new version of the extension PowerPack for Advance Steel which delivers additional tools and unique value to users. This version introduces more automation and functionality enabling them to boost their output and improve quality.
  • GRAITEC Advance BIM Designers collection of applications for Structural Design, Modeling and Documentation which run on multiple platforms including Revit, Advance Design, Advance Steel enabling flexible and intelligent structural BIM workflows.

It was a great pleasure meeting with Advance Steel users and hearing how they plan to prepare for a more connected future in steel fabrication.Michael Gustafson, Autodesk P.E. Industry Strategy Manager, Structural Engineering

The success and positive feedback of this event consolidated GRAITEC’s confidence in its BIM and CAD solutions and clearly strengthen its professionalism and position as an international BIM provider and Autodesk’s partner in North America.

This training was very beneficial, especially the session on PowerPack 2017. We discovered new features that we haven’t used yet that will help our detailing processes. The course on Management Tools Database also offered useful information presented to help with the proper management of Advance Steel.Magnus Rovillos, Steelway Building Systems

Read more about the agenda graitec.com/us/user_group.asp

Advance Steel 2017 & Advance Concrete 2017 now available


GRAITEC, an international BIM and CAD software developer for AEC, and Autodesk® Platinum Partner in US and across Europe, is pleased to announce that Autodesk® Advance Steel 2017 and Autodesk® Advance Concrete 2017 are now available from Autodesk.

GRAITEC, an international BIM and CAD software developer for AEC, and Autodesk® Platinum Partner in US and across Europe, is pleased to announce that Autodesk® Advance Steel 2017 and Autodesk® Advance Concrete 2017 are now available from Autodesk.

Autodesk® Advance Steel 2017 provides new features and enhancements to help improve productivity and usability whilst creating your fabrication documents more easily with tools to support a connected BIM workflow.

With new connections and profiles for international suppliers, more tools for cleaner documentation, options to manage Fabrication status data, and the ability to synchronise not just the structure but also the fully parametric steel connections with Revit, not to mention the ability to publish, share and collaborate with BIM360 using native Advance Steel drawing format – and whilst remaining connected to the source Advance Steel 3D model, Autodesk® Advance Steel 2017 delivers a more mature solution to create better coordinated designs and documentation.

Whilst Autodesk® Advance Concrete 2017 provides a more robust environment for completing and detailing concrete projects with links to Autodesk® Revit® for enhanced BIM centric workflow that supports an end-to-end solution.

Advance Steel is complimented with the GRAITEC PowerPack adding more functionality and further automating common repetitive tasks. PowerPack for Advance Steel can be downloaded directly from the Autodesk App Store as a free trial.

Other complementary solutions for Advance Steel available from GRAITEC include:

  • Steel Structure Designer – Create, adjust and configure complete structures of all shapes and sizes in minutes.
  • Ball Post Railing Designer – Adding ball post railings in Advance Steel is quick and simple with this dedicated ball post railing app.

Complimentary Reinforced Concrete design and detailing tools from GRAITEC include:

  • PowerPack for Revit – over 40 new tools dedicated to reinforced concrete modelling, editing and documentation.

Carl Spalding, Product Strategy Director comments:It is clear BIM is transforming how teams collaborate and build their projects across the globe. The Autodesk 2017 products are certainly ahead of the curve in delivering solutions to support their user’s needs for BIM centric workflows. This is evident from the harmonised structural steel workflows possible between Revit and Advance Steel dramatically reducing the initial design and rework effort for steel modelling and detailing.

Carl continuesBut this is just the tip of the iceberg. The biggest trend we are experiencing comes from the concrete sector frantically looking to replace traditional 2D detailing systems, which often break the BIM to fabrication workflow causing inevitable bottlenecks, with practical BIM-centric reinforced concrete solutions. The new reinforcement capability in Autodesk 2017 products, combined with complementary Add-ons and Apps from Graitec, demonstrate our commitment to delivering every-day reinforced concrete tools that support a BIM workflow. Looking ahead users can benefit from robust structural BIM workflows which promote the reuse of engineering BIM data, otherwise ignored when transferring project models, to enable structural projects to be completed more efficiently directly within Revit.

Boost your productivity with PowerPack for Advance Steel!


Boost your productivity with PowerPack

Download the Advance PowerPack now >>>

This Week Feature: Explode Details & Drawings

• Explode drawings from the Document Manager to .dwg format
• Instantly transforms Advance Steel dimensions into AutoCAD dimensions
• Dimensions retain their intelligence enabling editing in AutoCAD
• Select individual or multiple drawings

Video: Advance Steel Interoperability with Graitec Advance Workshop


This video shows how to quickly and accurately round trip fabrication information between Autodesk Advance Steel and Graitec Advance Workshop software. You will see:
– what information is exchanged between the two products
– how Advance Workshop utilizes this information in fabrication management
– how changes are synchronized and visualized using colorization of the 3D model in Advance Steel

Boost your productivity with PowerPack for Advance Steel!


Boost your productivity with PowerPack

Download the Advance PowerPack now >>>

This Week Feature: Curved Element Cut

  • Greater control and curved element cut options
  • Cut a straight tube, plate or folded beam by a curved tube
  • Fully control the cut contour
  • Easy to set and amend:
    • Number of points
    • Weld type and thickness
    • Cut offset
    • Contour shape



The GRAITEC PowerPack is a powerful extension to Autodesk® Advance Steel, designed to boost the user’s capability, productivity and efficiency. This PowerPack builds on the strength of the marketing leading Autodesk® Advance Steel by introducing a set of unique tools, templates and connections intentionally designed to enhance and speed up project delivery.

Boost your productivity with PowerPack for Advance Steel!


Boost your productivity with PowerPack

Download the Advance PowerPack now >>>

This Week Feature: Corrugated Beams

Create corrugated beams with this new feature
• Easily create a beam with an undulated web
• Use either a beam from the catalogue or user defined
• Control all dimensions that define the beam

PowerPack for Advance Steel - Corrugated-Beams

More tools in the new release of GRAITEC Advance PowerPack for Autodesk® Advance Steel 2016


GRAITEC, international BIM and CAD software developer for AEC and all round structural industry specialist, is delighted to deliver even more tools in the latest version of the Advance PowerPack for Autodesk® Advance Steel 2016.



Advance PowerPack for Autodesk® Advance Steel 2016



The new version of GRAITEC’s Advance PowerPack for Autodesk® Advance Steel includes a wealth of functionality and productivity tools to ensure customers achieve a true competitive advantage when using Autodesk® Advance Steel 2016.

The latest version, which is in addition to all previous tools, introduces several new connections, tools for setting out complex helical stair stringers, links with cloud services and a suite of commands for transforming Advance Steel drawings into AutoCAD compatible versions, whilst retaining intelligent scaled and editable dimensions.

Summary of new tools include:

GRAITEC customers receive the PowerPack for Advance Steel as a complimentary addition to their Autodesk® Advance Steel subscription and service contract, or it is available to purchase separately from GRAITEC or one of our global partners.



Download a free five day trial from the GRAITEC website.



Carl Spalding, GRAITEC Product Strategy Director comments:Initially the PowerPack was a way for us to deliver additional tools and unique value to customers. The rapid adoption by users around the world and the incredibly positive response has been very impressive. Each version introduces more tools, more automation, and more functionality enabling customers to boost their output and improve quality. It is encouraging to see how the tools we provide can make such a massive difference and it is no wonder the PowerPack is quickly becoming the must-have tool of a busy and competitive design office.
